EvolveSoundsInc
TARAMPS - 6" FH 300S 6-inch Loudspeaker (150 Watts RMS)
TARAMPS - 6" FH 300S 6-inch Loudspeaker (150 Watts RMS)
Regular price
$109.95 CAD
Regular price
$129.95 CAD
Sale price
$109.95 CAD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
TECHNICAL INFORMATION
RMS POWER | 150 W |
---|---|
MUSICAL PROGRAM POWER | 300 W |
NOMINAL IMPEDANCE | 4 or 8 ohms |
ELECTRIC RESISTANCE OF THE COIL WIRE | 3.0/5.6 ohms/VCC |
NO (EFFICIENCY REFERENCE) | 1.258% |
SENSITIVITY (@ 1W, 1M) - FREE-AIR | 93.015 dB |
DIAPHRAGM MASS | 0.018 lbs (8.348g) |
TOTAL MASS | 0.021 lbs (9.355g) |
PRODUCT BL | 5.317 TM |
MECHANICAL Q (QMS) | 3.791 |
ELECTRIC Q (QES) | 0.657 |
TOTAL Q (QTS) | 0.560 |
COMPLIANCE (CMS) | 243.761u M/N |
EQUIVALENT VOLUME (VAS) | 7.305 L |
FREQUENCY RESPONSE | 90Hz ~ 18.000Hz |
RESONANCE FREQUENCY | 105.393Hz |
CONE EFFECTIVE AREA (SD) | 0.0145 Sq.m |
CONE EXCURSION WITHOUT DISTORTION (X MAX) | - + 0.14" (3,7 mm) |
FLOW DENSITY IN THE GAP | 10.700 GAUSS |
NOMINAL DIAMETER | 6" |
FERRITE MEASUREMENTS | 4.52" x 2.20" x 0.70" (115 x 56 x 18 mm) |
COIL DIAMETER | 1.1/2" |
COIL HEIGHT | 0.41" (10,5mm) |
COIL WIRE MATERIAL | CCAW |
COIL WIRE SECTION | Round |
COIL SHAPE | *Kapton® |
GAP HEIGHT | 0.25" (6,35mm) |
HOUSING MATERIAL | Steel |
FERRITE MATERIAL | Barium |
WEIGHT | 4.32 lb (1.96 Kg) |
VOLUME OCCUPIED IN THE CABINET | 0,60 Litros |
EAN | 4 ohms: 7898556845236 8 ohms: 7898556845243 |
